AM1DR-0503SJZ

AM1DR-0503SJZ

Image is for reference,
please contact us to get the real picture

Part No :

AM1DR-0503SJZ

Manufacturer
DComponents
Description
DC DC CONVERTER 3.3V 1W
Catalog
DC DC Converters
Shipped from
HK warehouse
Expected Shipping Date
Oct 08 - Oct 12 2025
DataSheet
AM1DR-0503SJZ PDF
Availability
291 pieces
Unit Price
$2.80000

Current price of AM1DR-0503SJZ is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

AM1DR-0503SJZ Specifications
Type Description
Series:AM1DR-NZ (1W)
Package:Tube
Part Status:Active
Type:Isolated Module
Number of Outputs:1
Voltage - Input (Min):4.75V
Voltage - Input (Max):5.25V
Voltage - Output 1:3.3V
Voltage - Output 2:-
Voltage - Output 3:-
Voltage - Output 4:-
Current - Output (Max):250mA
Power (Watts):1 W
Voltage - Isolation:1.5 kV
Applications:ITE (Commercial)
Features:-
Operating Temperature:-40°C ~ 71°C (With Derating)
Efficiency:67%
Mounting Type:Through Hole
Package / Case:7-SIP Module, 4 Leads
Size / Dimension:0.77" L x 0.24" W x 0.38" H (19.7mm x 6.0mm x 10.2mm)
Supplier Device Package:-
Control Features:-
Approval Agency:cULus, cURus
Standard Number:-
