AM2F-0507SH30Z

Part No :: AM2F-0507SH30Z

Manufacturer: DComponents

VIGOR # :: 4109196

Description: DC DC CONVERTER 7.2V 2W

Catalog: DC DC Converters

DataSheet: AM2F-0507SH30Z PDF

Country of origin: -

Date code: -

AM2F-0507SH30Z Specifications

Type	Description
Series:	AM2F-Z (2W)
Package:	Tube
Part Status:	Active
Type:	Isolated Module
Number of Outputs:	1
Voltage - Input (Min):	4.5V
Voltage - Input (Max):	5.5V
Voltage - Output 1:	7.2V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	278mA
Power (Watts):	2 W
Voltage - Isolation:	3 kV
Applications:	ITE (Commercial)
Features:	-
Operating Temperature:	-40°C ~ 71°C (With Derating)
Efficiency:	64%
Mounting Type:	Through Hole
Package / Case:	12-SIP Module, 7 Leads
Size / Dimension:	1.26" L x 0.32" W x 0.55" H (32.0mm x 8.0mm x 14.0mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
AM2F-0509SH52Z Match 64%	DComponents DC DC CONVERTER 9V 2W	AM2F-0507SH30Z vs AM2F-0509SH52Z
AM2F-0507SZ Match 86%	DComponents DC DC CONVERTER 7.2V 2W	AM2F-0507SH30Z vs AM2F-0507SZ
AM2F-0507SH52Z Match 93%	DComponents DC DC CONVERTER 7.2V 2W	AM2F-0507SH30Z vs AM2F-0507SH52Z
AM2F-0509SH30Z Match 71%	DComponents DC DC CONVERTER 9V 2W	AM2F-0507SH30Z vs AM2F-0509SH30Z
AM2F-0505SH30Z Match 53%	DComponents DC DC CONVERTER 5V 2W	AM2F-0507SH30Z vs AM2F-0505SH30Z
