PT5107N

Part No :: PT5107N

Manufacturer: VIGOR

VIGOR # :: 4134099

Description: SWITCHING REGLTR, VOLTAGE-MODE

Catalog: DC DC Converters

DataSheet: PT5107N PDF

Country of origin: -

Date code: -

PT5107N Specifications

Type	Description
Series:	PT5100
Package:	Tray
Part Status:	Obsolete
Type:	Linear Regulator Replacement
Number of Outputs:	1
Voltage - Input (Min):	19V
Voltage - Input (Max):	38V
Voltage - Output 1:	15V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	1A
Power (Watts):	15 W
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	OCP, OTP
Operating Temperature:	-40°C ~ 85°C
Efficiency:	95%
Mounting Type:	Through Hole
Package / Case:	3-SIP Module
Size / Dimension:	1.00" L x 0.38" W x 1.02" H (25.4mm x 9.7mm x 25.9mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
R-78C15-1.0 Match 100%	RECOM Power DC DC CONVERTER 15V 15W	PT5107N vs R-78C15-1.0
R-78C12-1.0 Match 69%	RECOM Power DC DC CONVERTER 12V 12W	PT5107N vs R-78C12-1.0
PT5107S Match 100%	Texas Instruments DC DC CONVERTER 15V 15W	PT5107N vs PT5107S
PT5102S Match 69%	Texas Instruments DC DC CONVERTER 12V 12W	PT5107N vs PT5102S
PT5102N Match 69%	Texas Instruments DC DC CONVERTER 12V 12W	PT5107N vs PT5102N
