PTB78560BAZ

Part No :: PTB78560BAZ

Manufacturer: VIGOR

VIGOR # :: 4154521

Description: DC-DC POWER SUPPLY MODULE

Catalog: DC DC Converters

DataSheet: PTB78560BAZ PDF

Country of origin: -

Date code: -

PTB78560BAZ Specifications

Type	Description
Series:	PTB78560 (30W)
Package:	Tray
Part Status:	Obsolete
Type:	Isolated Module
Number of Outputs:	1
Voltage - Input (Min):	18V
Voltage - Input (Max):	60V
Voltage - Output 1:	1.8 ~ 3.6V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	8A
Power (Watts):	30 W
Voltage - Isolation:	1.5 kV
Applications:	ITE (Commercial)
Features:	Remote On/Off, OCP, OTP, UVLO
Operating Temperature:	-40°C ~ 85°C
Efficiency:	80%
Mounting Type:	Surface Mount
Package / Case:	11-SMD Module
Size / Dimension:	2.04" L x 1.04" W x 0.40" H (51.8mm x 26.5mm x 10.3mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
PTB78560AAZ Match 82%	Texas Instruments DC DC CONVERTER 3.6-5.5V 30W	PTB78560BAZ vs PTB78560AAZ
PTB78560BAS Match 67%	VIGOR DC-DC REGULATED POWER SUPPLY MOD	PTB78560BAZ vs PTB78560BAS
