PT5046A

Part No :: PT5046A

Manufacturer: Texas Instruments

VIGOR # :: 5016957

Description: DC DC CONVERTER 10V

Catalog: DC DC Converters

DataSheet: PT5046A PDF

Country of origin: -

Date code: -

PT5046A Specifications

Type	Description
Series:	PT5040
Package:	Tray
Part Status:	Obsolete
Type:	Non-Isolated PoL Module
Number of Outputs:	1
Voltage - Input (Min):	4.75V
Voltage - Input (Max):	9V
Voltage - Output 1:	10V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	1.2A
Power (Watts):	-
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	-
Operating Temperature:	-20°C ~ 85°C
Efficiency:	85%
Mounting Type:	Through Hole, Right Angle
Package / Case:	3-SIP Module
Size / Dimension:	-
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
PT5541A Match 63%	VIGOR SWITCHING REGLTR, VOLTAGE-MODE	PT5046A vs PT5541A
PT5041M Match 63%	VIGOR SWITCHING REGLTR, VOLTAGE-MODE	PT5046A vs PT5041M
PT5041G Match 63%	Texas Instruments DC DC CONVERTER 12V	PT5046A vs PT5041G
PT5041A Match 63%	Texas Instruments DC DC CONVERTER 12V	PT5046A vs PT5041A
PT5046M Match 100%	Texas Instruments DC DC CONVERTER 10V	PT5046A vs PT5046M
PT5546A Match 95%	Texas Instruments DC DC CONVERTER 10V	PT5046A vs PT5546A
