Part No :

56300-10

Manufacturer
Wickmann / Littelfuse
VIGOR # :

8354887

Description
ROCKER SWITCH
Catalog
Rocker Switches
DataSheet
56300-10 PDF
Country of origin
Confirming
Date code
TBC
ads
Type Description
Series:56000
Package:Bulk
Part Status:Obsolete
Mounting Type:Panel Mount, Snap-In
Circuit:SPST
Switch Function:On-Off
Current Rating (Amps):25A (DC)
Voltage Rating - AC:-
Voltage Rating - DC:12 V
Actuator Type:Concave (Standard V) - Illuminated
Color - Actuator/Cap:White
Actuator Marking:No Marking
Illumination Type, Color:Incandescent, Green
Illumination Voltage (Nominal):12 VDC
Termination Style:Quick Connect - 0.250" (6.3mm)
Ingress Protection:-
Features:-
Panel Cutout Dimensions:Rectangular - 36.83mm x 21.08mm
Operating Temperature:-
