GPA020A135MN-FD

Part No :: GPA020A135MN-FD

Manufacturer: SemiQ

VIGOR # :: 4588491

Description: IGBT 1350V 40A 223W TO3PN

Catalog: Transistors - IGBTs - Single

DataSheet: GPA020A135MN-FD PDF

Country of origin: -

Date code: -

GPA020A135MN-FD Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
IGBT Type:	Trench Field Stop
Voltage - Collector Emitter Breakdown (Max):	1350 V
Current - Collector (Ic) (Max):	40 A
Current - Collector Pulsed (Icm):	60 A
Vce(on) (Max) @ Vge, Ic:	2.3V @ 15V, 20A
Power - Max:	223 W
Switching Energy:	2.5mJ (on), 760µJ (off)
Input Type:	Standard
Gate Charge:	180 nC
Td (on/off) @ 25°C:	25ns/175ns
Test Condition:	600V, 20A, 10Ohm, 15V
Reverse Recovery Time (trr):	425 ns
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Through Hole
Package / Case:	TO-3
Supplier Device Package:	TO-3P
